QUICK-TURN PCB MANUFACTURING

Quick-Turn PCB manufacturing from our UK facility, delivering accelerated lead times through controlled processes and dedicated engineering oversight.

HOW OUR QUICK-TURN SERVICE WORKS

When schedules compress, Exception PCB's Quick-Turn service provides an engineering-led route to accelerated manufacture without trading away quality or process control. We support time-critical prototype and production builds where certainty matters as much as speed.

Our engineers take on each Quick-Turn build directly, assessing feasibility quickly, confirming what is achievable, and managing the job through to dispatch. Customers get honest answers upfront and a clear line of communication throughout, so there are no surprises when time is already tight.

LET OUR ENGINEERS ASSESS YOUR LEAD-TIME OPTIONS

Whether you are recovering lost time or keeping a programme on track, our team will review your design and confirm what Quick-Turn can achieve.

Talk to our engineers

QUICK-TURN MANUFACTURING PROCESS

Every Quick-Turn build follows the same controlled manufacturing route, with each stage managed to protect both delivery and quality.

STAGE 1

ENGINEERING AND CAM REVIEW

Design data is reviewed promptly to confirm feasibility, scope, and priority. Our engineers assess stack-up, materials, drill structures, impedance, and tolerances before production is released.

STAGE 2

INNER LAYER IMAGING AND AOI

Inner layers are produced using precision imaging and etching. Automated optical inspection verifies track definition, spacing, and registration before lamination.

STAGE 3

LAMINATION

Inspected inner layers are laminated under controlled temperature and pressure, ensuring consistent bonding, resin flow, and layer alignment.

STAGE 4

DRILLING AND PLATING

Interconnections are formed through mechanical and laser drilling, followed by automated copper deposition to build conductive paths and via structures.

STAGE 5

OUTER LAYER IMAGING AND AOI

Outer circuitry is defined through imaging and etching, with automated optical inspection confirming pattern integrity and registration.

STAGE 6

ELECTRICAL TEST

All boards undergo 100% electrical testing to verify continuity and isolation across every net.

STAGE 7

FINAL INSPECTION AND DISPATCH

Completed boards are verified, documented, and dispatched with clear communication maintained throughout the build.

A detailed close-up of a blue printed circuit board showing trace routing and integrated circuit component pads.

QUICK-TURN LEAD TIMES

Availability is confirmed at enquiry stage and depends on design complexity, materials, and current production loading.

  • Some qualifying designs can be delivered within a matter of days
  • Lead times vary based on layer count, materials, routing density, and inspection requirements
  • Cut-off times and delivery dates are confirmed once data and scope are agreed
Two Exception PCB technicians working at ATG electrical test machines in a dedicated PCB test room.

QUALITY AND ASSURANCE

Speed does not change our quality standards. No inspection or verification steps are bypassed to achieve faster delivery.

OUR QUALITY CONTROLS INCLUDE:

  • AOI on internal and external layers
  • 100% electrical test
  • Microsection analysis where required
  • Full material and process traceability
  • Controlled documentation and inspection records

This ensures accelerated builds remain suitable for validation, integration, and follow-on manufacture.
